Our Products

MR12

Maximum static load: 2600 kg
Reduction ratio: 1/52; 1/45; 1/43; 2/53; 2/43
Gear weight: 240 kg
Oil capacity: 3.8 l (Shell Omala S4 WE)
Power range VVVF: 2.7 - 6 kW 50/60 Hz
Power range AC2: 2.7 - 6 kW 50/60 Hz
Produced for system with a 480 kg capacity.
View product

MR13

Maximum static load: 2600 kg
Reduction ratio: 1/52; 1/45; 1/43; 2/53; 2/43; 3/47
Gear weight: 250kg
Oil capacity: 4.2 l (Shell Omala S4 WE)
Power range VVVF: 2.6 - 8.2 kW 50/60 Hz
Power range AC2: 2.6 - 6 kW 50/60 Hz
View product

MR14

Maximum static load: 3300 kg
Reduction ratio: 1/74; 1/65; 1/58; 1/52; 1/49; 1/45; 2/53; 2/71; 3/47
Gear weight: 250 kg
Oil capacity: 4.8 l (Shell Omala S4 WE)
Power range VVVF: 2.6 - 10 kW 50/60 Hz
Power range AC2: 2.6 - 7.4 kW 50/60 Hz
View product

MR17

Maximum static load: 5200 kg
Reduction ratio: 1/55; 1/43; 1/35; 2/43; 3/41
Gear weight: 550 kg
Oil capacity: 8.5 l (Shell Omala S4 WE)
Power range VVVF: 5.5 - 15 kW 50/60 Hz
Power range AC2: 5.5 - 15 kW 50/60 Hz
View product

MR21

Maximum static load: 5600kg (7400kg for MR21TS)
Reduction ratio: 1/62; 1/51; 1/40; 2/63; 2/51; 3/47
Gear weight: 770-1000kg
Oil capacity: 7.8 lt (ShellOmalaS4WE)
Power range VVVF: 7.5 - 33 kW 50/60 Hz
Power range AC2: 7.5 - 22 kW 50/60 Hz
View product
